Autonics E30S4-1024-3-N-24 Rotary Encoder
0৳
Product Details:
| Encoder Type | Rotary |
| Material | Mild Steel |
| Resolution | 1024 PPR |
| Brand | Autonics |
| Usage/Application | Industrial |
| Color | Black |
| Model Number | E30S4-1024-3-N-24 |
| Supply Voltage | 12-24 VDC (12-24 V) |
| Output Type | NPN Open Collector |
| Hollow Shaft Diameter | 04mm |
| Power Supply Voltage | 12-24vdc |
| Shaft Diameter | 6 mm |
| Output Phases | Phases A; B; and Z |
| Protection Rating | IP50 |
| Shaft Type | Solid Shaft |
| Outer Diameter | 28 mm |
- Shaft outer diameter : Ø4mm
- Max. response frequency : 300kHz
- Max. allowable revolution : 5000rpm
- Starting torque : Max. 20gf.cm(max. 0.00196N.m)
- Resolution : 1024P/R
- Control output : NPN open collector
- Power supply : 12-24VDC ±5%(ripple P-P: max. 5%)
- Connection type : Axial cable type
- Protection structure : IP50
