| Display method | 4-digit 7-segment LCD |
|---|---|
| Operation method | Count up, Count down |
| Output Operation | ON DELAY, INTERVAL, FLICKER, ON-OFF DELAY, OFF DELAY |
| Time operation | SIGNAL ON START |
| Terminal | 8-pin plug |
| Power voltage | 24-240VAC~, 24-240VDC  |
| Setting range | 0.01 sec to 9.999 sec, 0.01 sec to 99.99 sec, 0.1 sec to 999.9 sec, 1 sec to 9999 sec, 0 min 1 sec to 99 min 59 sec, 0.1 min to 999.9 min, 1 min to 9999 min, 0 hour 1 min to 99 hour 59 min, 0.01 hour to 99.99 hour, 0.1 hour to 999.9 hour, 1 our to 9999 ho |
| Signal Input Method | No-voltage input(NPN) |
| Control output_Relay | Time-limit SPDT (1c): 1 |
| Backlight | Backlight function |
| Min. signal Width_START | 1ms, 20ms (selectable) |
| Min. signal Width_INHIBIT | 1ms, 20ms (selectable) |
| Min. signal Width_RESET | 1ms, 20ms (selectable) |
| Accessories | Bracket |
| Environment_Ambient temperature | -10 to 55℃, storage: -25 to 65℃ |
| Environment_Ambient humidity | 35 to 85%RH |
| Weight | Approx. 98g |
※Sockets (PG-08, PS-08(N)) are sold separately.
※The temperature or humidity mentioned in Environment indicates a non freezing or condensation environment.
※The weight includes packaging. The weight in parenthesis is for unit only.
