Sm-Cc Crb1bw80-90d Crb1 Series Rotary Actuator Vane Type
0৳
SM-CC Crb1bw80-90d Crb1 Series Rotary Actuator Vane Type
Specifications: CRB1 Series Rotary Actuator Vane Type
Possible to move the auto switch mounting position as desired
Direct mounting
Connection port position: Side ported and axial ported selectable
Low pressure operation: 0.15 MPa (Sizes 50 to 100)
With auto switch (Series CDRB1: CDRB1, CDVRB1)
Direct mounting
Connection port position: Side ported and axial ported selectable
Low pressure operation: 0.15 MPa (Sizes 50 to 100)
With auto switch (Series CDRB1: CDRB1, CDVRB1)
| Field | Value | Value Details |
|---|---|---|
| With Auto Switch(Built-in Magnet) | – | Without Auto Switch |
| Mounting Style | B | Basic |
| Shaft Type | W | Double Shaft (Long Shaft Key & Four Chamfers) |
| Size | 80 | 80 |
| Option 1 | – | Standard |
| Rotation Angle | 90 | 90° |
| Vane Type | D | Double Vane |
| Connecting Port | – | Side Ported |
| Option 2 | – | Standard |
| Auto Switch | – | Without Auto Switch |
| Number Of Auto Switches | – | 2 pcs. Or None |
| Made To Order | – | Standard/Rc |
