Twin Rod Guided Air Cylinder Cxsm25-100-Z73, Bore 25mm Stroke 100mm, Slide Bearing, Anti-Rotation Pick & Place Pneumatic Cylinder

This original Japanese-manufactured CXSM25-100-Z73 belongs to classic CXSM high-rigidity twin rod cylinder series, equipped Φ25mm bore and standard 100mm stroke, adopting parallel double piston rod integrated slide bearing guide structure, ultra-low torsion tolerance ±0.2°, perfect for linear pushing, lifting and clamping scenarios requiring high anti-rotation precision. Built-in permanent magnetic ring inside piston, pre-assembled two Z73 magnetic auto switches with 0.5m standard lead wire for real-time stroke position signal feedback to PLC control system. Double acting air circuit design delivers stable bidirectional thrust, front and rear ends adopt rubber bumper cushion to absorb impact force and reduce operation noise. Standard Rc1/8 internal thread air port for convenient tubing connection, aluminum alloy hard anodized cylinder tube with wear-resistant PU piston seal, long service life and low internal air leakage. Multi-direction mounting holes support bottom, top and side installation to adapt compact fixture layout, adjustable stroke buffer up to 5mm on each side. Wide 0.05~0.7MPa universal industrial compressed air pressure range, piston speed 30~600mm/s compatible with high-speed assembly lines. Widely applied to automated assembly fixture pushing, packaging machine material ejection, logistics conveyor stopper, robotic workstation clamping mechanism and small CNC equipment positioning drive. Original factory sealed packaging includes dimension drawing, port wiring diagram and full English official datasheet for pneumatic circuit design and bulk spare parts inventory management.
