- Standards Compliance: IEC 60947-5-1, GB/T 14048.5
- Rated Operating Voltage (Ue): AC 380V / DC 220V
- Rated Thermal Current (Ith): 10A
- Rated Operating Current (Ie):
- AC-15: 380V / 4A
- DC-13: 220V / 0.3A
- Rated Insulation Voltage (Ui): 500V
- Contact Configuration: 1NO + 1NC (snap-action type)
- Contact Resistance: ≤ 25mΩ
- Insulation Resistance: ≥ 100MΩ (at 500V DC)
- Dielectric Strength: 2500V AC, 1 min between contacts and terminals
- Actuator Types:
- Roller lever (adjustable/fixed)
- Roller plunger
- Top plunger
- Rod lever and fork lever options
- Mechanical Life: ≥ 10 million operations
- Electrical Life: ≥ 500,000 operations
- Operating Frequency: 120 operations/minute (mechanical)
- Protection Degree: IP65 (dust-tight and water-jet resistant)
- Ambient Temperature: −25°C to +70°C
- Relative Humidity: ≤ 90% at +20°C
- Mounting Method: Screw mounting; adjustable head for flexible installation
- Housing Material: Reinforced thermoplastic or aluminum alloy body
- Weight: Approx. 0.2–0.3 kg depending on model
